Super Handy GUO084 - EXPLODED DRAWINGS; Part Identification Diagram

Part No.
1
3
4
5
6
7
8
9
10
11
Description
R Pin
8 " Wheel
Bottom Plate
Flange Nut M8
Hexagon Flange Bolt M8x50mm
Hydraulic Cylinder Kit
Oil Dipstick
Spring Washer
Outer hexagon bolt M10x 30mm
Hexagon Flange Bolt M8x25mm
Q’ty
2
2
1
8
4
1
1
4
4
4
Part No.
12
13
14
15
16
17
18
19
20
21
Description
Primary Beam Kit
Hexagon Flange Bolt M6x35mm
Handle
Flange Nut M6
Supporting Bar
Filter
Elastic Ring
Hose Clamp
Oil Hose
Electromotor
Q’ty
1
1
1
1
1
1
1
2
1
1
EXPLODED DRAWINGS
9
20
1
3
6
7
5
21
4
18
(5)
19
(5)
16
8 9 10
(6)
11
13
14 15
12
(19)
17
