Super Handy GUO084 - Table of Contents; Technical Specifications

1
INDEX
TECHNICAL SPECIFICATIONS ---------------------------------------------------------------------------------------------------------- 1
SAFETY DEFINITIONS ---------------------------------------------------------------------------------------------------------------------- 2
SAFETY SYMBOLS ----------------------------------------------------------------------------------------------------------------------- 2
SAFETY GUIDELINES ------------------------------------------------------------------------------------------------------------------- 4
ELECTRICAL SAFETY ---------------------------------------------------------------------------------------------------------------------
CONTROLS AND FEATURES ----------------------------------------------------------------------------------------------------------- 5
PARTS LIST ----------------------------------------------------------------------------------------------------------------------------------- 6
EXPANDED DRAWINGS ------------------------------------------------------------------------------------------------------------------ 9
MAINTENANCE AND STORAGE ------------------------------------------------------------------------------------------------------ 11
TROUBLE SHOOTING -------------------------------------------------------------------------------------------------------------------- 11
TECHNICAL SPECIFICATIONS
Maximum Exerted Splitting Force
Electromotor Specifications
Starter Type
Cycle Time
Gear Pump
Control Valve
Hydraulic Cylinder Stroke Length
Max Log Length
Max Log Diameter
Hydraulic Fluid Type
Hydraulic Fluid Tank Capacity
Wheel Diameter
Wire length
Net Weight
Overall Dimensions(L x W x H)
14 (US tons)
120V, 60Hz, 15A, 1700RPM
Electric Start
16.5sec.
10GPM / 38LPM
Detent (auto-return)
16"
20.5"
16"
AW32, AW46
2.1Gal. (8L)
8"
70.9"
126LB
47.09" x 14.02" x 33.98"（Assembled）
