BT Series Electric Boilers – Installation, Operating and Maintenance Instructions
2
Dimensions and Specifications Section 1
1.1 TECHNICAL SPECIFICATIONS
Maximum Operating Pressure: 90 p.s.i.
Maximum Operating Water Temperature: 210ºF
Water Capacity in Boiler: 6.6 US Gallons
Inlet and Outlet Pipe Size: 1 1/4” NPT
Controller Pump Switch Capacity: 5A Maximum
Table 1: Super Hot BT Series Electric Boiler Specifications. (Flange Type Elements)
Single Phase Three Phase
Super Hot
BT Series Electric Boilers
208 Vac 240 Vac 208 Vac 240 Vac 480 Vac 600 Vac
Model kW Btu/Hr Amp Amp Amp Amp Amp Amp
6BT 6 20,474 28.9 25.0 16.7 14.4 7.2 5.8
9BT 9 30,708 43.3 37.5 25.0 21.6 10.8 8.7
12BT 12 40,848 57.7 50.0 33.3 28.8 14.4 11.5
15BT 15 51,185 72.1 62.5 41.6 36.0 18.0 14.4
18BT 18 61,422 86.5 75.0
54.6* 47.3* 23.7* 18.9*
20BT 20 68,240 96.2 84.3
63.6* 55.1* 27.6* 22.0*
24BT 24 81,895 115 100 66.5 57.7 28.8 23.1
27BT 27 92,124 130 113 74.9 64.9 32.4 26.0
30BT 30 102,369 144 125 83.2 72.1 36.0 28.8
34BT 34 116,008 164 142
100* 87.0* 43.5* 34.8*
38BT 38 129,656 183 158
118* 102* 50.5* 40.4*
42BT 42 143,304 202 175 116 101 50.5 40.4
45BT 45 153,540 216 188 125 108
57.7* 46.2*
48BT 48 163,776 231 200
138* 119* 59.6* 47.7*
54BT 54 184,248 260 225 150 130 64.9 52.0
Note:
1. Other models of the BT Series Electric Boiler may be available subject to inquiry.
2. * Delta connection (unbalanced load) amperage of high leg indicated.
3. Approximate shipping weights:
Model Weight
Ŧ
6BT & 9BT 114 lb
12BT to 18BT 116 lb
20BT & 24BT 118 lb
27BT to 38BT 122 lb
42BT to 54BT 126 lb
Ŧ
Add 45 lb for package models
