SUPER73 Super73-S2 - Adjusting Rebound

19
Adjusting Rebound
Rebound is adjusted with the dial located on the bottom of the right stanchion.
• Turn the rebound dial clockwise to slow your suspension rebound
(damper increase).
• Turn the rebound dial counterclockwise to speed up the rebound
(damper decrease).
SUGGESTED STARTING FORK AIR PRESSURE
LBS KG PSI BAR
125 57 70 4.8
145 66 78 5.4
165 75 86 5.9
185 84 94 6.5
205 93 102 7.03
225 102 110 7.6
245 111 118 8.1
265 120 126 8.7
285 129 134 9.2
305 138 142 9.8
325 148 150 10.3
Fork Pressure Limits
Minimum: 70 PSI
Maximum: 150 PSI
Figure 1
