Allow Temp 1 Calibration: Allows an
administrator to select if the calibration values of
Temp 1 are on LOCK (selected in Figure 5.10) or
UNLOCK. If UNLOCK is selected the calibration
values can be changed.
Temperature sensors are not calibrated channels/
sensors. If a temperature is reading incorrectly,
try using a di󰀨erent probe/sensor. If available,
temperature reading may be veried with a known
temperature source, temperature dry-block or
thermocouple simulator. If the actual (sensor)
and veried (source) readings are o󰀨 more than
+/- 2.0°F, the owbench reading can be adjusted by
entering the di󰀨erence between the actual (sensor)
and veried (source) readings as the O󰀨set value.
Click the current O󰀨set value to open a popup
window that allows the administrator to enter the
new value.
5
Allow Temp 2 Calibration: Allows an
administrator to select if the calibration values of
Temp 2 are on LOCK (selected in Figure 5.10) or
UNLOCK. If UNLOCK is selected the calibration
values can be changed.
Temperature sensors are not calibrated channels/
sensors. If a temperature is reading incorrectly,
try using a di󰀨erent probe/sensor. If available,
temperature reading may be veried with a known
temperature source, temperature dry-block or
thermocouple simulator. If the actual (sensor)
and veried (source) readings are o󰀨 more than
+/- 2.0°F, the owbench reading can be adjusted by
entering the di󰀨erence between the actual (sensor)
and veried (source) readings as the O󰀨set value. Click the current O󰀨set value to open a popup window
to enter the new value.
Figure 5.10: Sensor Calibration
1
2
3
4 5
