65
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Installation and Operation Instructions
900299-00, 05/2016
Innovative Hearth Products
DRT40 Multi-View Series Direct-Vent Gas Fireplace
NOTE: Ordering information for Volcanic Stone, Glowing Embers and Touch-up Paint can be found on Page 57.
REPLACEMENT PARTS LIST
No. Description Part No. DRT40ST DRT40PF DRT40CL DRT40CR
1 Hood (Black) 24" J7537 0 1 1 1
2 Hood (Black) 40" J7536 2 2 1 1
3 Glass Enclosure Assembly 24" H6336 0 1 1 1
4 Glass Enclosure Assembly 40" H8122 2 2 1 1
5 Log Set 55M04 1 1 1 1
6 Grate Assembly H6287 1 1 1 1
7 Burner Assembly 55M42 1 1 1 1
9 Gasket, Venturi Tube Mounting 43K85 1 1 1 1
10 Venturi Tube Arm 42M80 1 1 1 1
11 Switch, Rocker 80L41 1 1 1 1
12 Air Shutter Adjustment Rod H6321 1 1 1 1
13 Flexline Gas Conductor 93L32 1 1 1 1
14 Barrier, Front J7420 2 2 1 1
15 Barrier, End J7421 0 1 1 1
16 Front Face Assembly with Barrier J7530 2 2 1 1
17 End Face Assembly with Barrier J7531 0 1 1 1
--- Superior
®
Badge (logo) J8150 1 1 1 1
WARNING
Failure to position the parts in accordance with these
diagrams or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.
AVERTISSEMENT
Risque de dommages ou de blessures si les pièces
ne sont pas installées conformément à ces schémas
et ou si des pièces autres que celles spécifiquement
approuvées avec cet appareil sont utilisées.
