NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS LIST
Natural Propane
No. DESCRIPTION Part No. Qty. Part No. Qty.
Gas Fireplace Assembly –– ––
1. Firescreen 161108 2 161108 2
2. Rod, Screen 498168 2 498168 2
3. Refractory, Side LB-98313B 2 LB-98313B 2
4. Refractory, Rear LB-98314B 1 LB-98314B 1
5. Refractory Access Panel LB-97388A 1 LB-97388A 1
6. Refractory, Base (Left) LB-97267 1 LB-97267 1
7. Refractory, Base (Right) LB-97268 1 LB-97268 1
8. Log Set, Complete 75L51 1 75L51 1
a. Log, Front 82L5401 1 82L5401 1
b. Log, Back 82L5501 1 82L5501 1
c. Log, Top Right 82L4701 1 82L4701 1
d. Log, Top Center 82L4901 1 82L4901 1
e. Log, Top Left 82L4801 1 82L4801 1
9. Burner Assembly LB-97336 1 LB-97336 1
10. Burner Orifice 18L4001 1 74L8801 1
11. Bag of Rockwool 88L53 1 88L53 1
12. Limit Switch 62L1601 1 62L1601 1
13. Damper Switch 82L5901 1 82L5901 1
GAS CONTROLS — ELECTRONIC
Natural Propane
No. DESCRIPTION Part No. Qty. Part No. Qty.
30. Gas Valve - Honeywell 62L1801 1 62L1901 1
31. Pilot Assembly (Honeywell) 62L1401 1 62L1501 1
32. Transformer 42J3201 1 42J3201 1
33. Ignitor Assembly (Kit) 87L54 1 87L54 1
GAS CONTROLS — MILLIVOLT
Natural Propane
No. DESCRIPTION Part No. Qty. Part No. Qty.
*20. Gas Valve - SIT H165801 1 H165901 1
*21. Gas Valve - Honeywell 62L0501 1 62L0501 1
22. Pilot Assembly (SIT) 62L1201 1 62L1301 1
23. Pilot Generator 60J7901 1 60J7901 1
24. Electrode And Cable 74L5801 1 74L5801 1
**25. Piezo Ignitor 111061 1 111061 1
**26. Ignition Cable 902164 1 902164 1
27. Pilot Tube 74L5601 1 74L5601 1
*Appliances may be fitted at the factory with either a Honeywell or SIT Millivolt gas control valve.
**For SIT gas valve equipped appliances only.
