Installation
900285-00 05/2015
Innovative Hearth Products
Superior
TM
DRT/C3000 Series Direct-Vent Gas Fireplaces
45
Step 1. Slide top trim pieces over flange of panel until seated squarely. Step 2. Slide side trim pieces into place (top will overlap slightly). Repeat
Step 1 and Step 2 for bottom and opposite side trim for panel.
NOTE: Remove protective flim from all stainless components
before installation.
Step 3. Plug lead wires into the IPI/CPI Switch on right side of
facade base.
Installing Facade
