5) Unscrew a fixing bracket (1) from the stove, slide the fascia into the other bracket (2) then carefully attach the
previously removed bracket onto the fascia (3) and screw the bracket and the fascia back on. Compensate for
any slack with the fibreglass provided (see diagram).
6) Replace the top plate and tighten up the fixing screws.
HANDLE THE CERAMIC PANEL WITH CARE.
Fibreglass tape as
required
TOP PLATE
CERAMIC
FASCIA
FASCIA FIXING
BRACKET
1
2
4
3
5
( unscrew )
35
