Superior MONIA - Product Identification and Data Plates; Stove Dimensions and Measurements

H07023380 / DT2000477-03
54
6
18
! 8scarico
18
Dimensioni in cm
48
99
33 *
8,3
27
* Quota minima da rispettare per scarico laterale (optional)
Every product is identifi ed by a rating plate showing the model and the performance of the appliance as well as a plate giving the serial number.
The rating plate is located on the rear panel of the stove, while the plate with the serial number is located on the underside of the hopper lid.
A label bearing the serial number is also applied on the cover last page of the “Installation, operation and maintenance” booklet.
Always give the information shown on these plates to the dealer or the Service Centre when requesting service or spare parts.
DT2032205-0
NOME
PRODOTTO
DT2032204-0
NUMERO MATRICOLA
English
2.4 PRODUCT IDENTIFICATION DATA
DT2011541-00
2.5 DIMENSIONS
DT2032294-00
Fig. 24
Fig. 25
PRODUCT
NAME
SERIAL NUMBER
Measurements in cm.
* Minimum measurement for the side flue gas outlet (optional).
