14
Pinch or squeeze the clip lever to open the clip, and
through the slot in the inboard (right) end of the drum.
The take-up fastener is designed to automatically take
up any slack caused by stretching of the abrasive
wrap. The abrasive wrap may stretch enough in use
to allow the take-up lever to reach its lowest position
so it no longer is able to maintain tension on the wrap.
lever by raising it, pushing the wrap end into the slot,
and then releasing the clip lever.
NOTE: Take notice that for detail only the drum was removed
to show the inboard (right) take-up fastener.
PROPER ABRASIVE WRAP POSITION
room between the inside of the slot and the tapered
end of the wrap to allow it to be pulled into the drum
not left between the wrap and the inside of the slot the
take-up fastener will not operate properly.
ABRASIVE WRAP TENSION ADJUSTMENT
The abrasive wrap may stretch enough in use to allow
-
curs then tension is not longer maintained on the abra-
it, pushing the abrasive wrap into the slot and then re-
leasing the clip lever.
MAXIMIZING ABRASIVE LONGEVITY
A sandpaper cleaning stick may be used to remove deposits and help extend the life of the abrasive.
1. To use the cleaning stick, operate the sanding drum with the dust cover open and dust collection on.
2.
3. Use a shop brush to remove any cleaning stick remnants from the drums before resuming sanding operations.
FOR YOUR OWN SAFETY ALWAYS WEAR EYE PROTECTION WHILE PERFORMING ABRASIVE CLEANING
AND TAKE ALL PRECAUTIONS TO AVOID ANY CONTACT WITH HANDS OR CLOTHING ON THE UNCOVERED.
3
4
