6
SPECIFICATIONS
Maximum Width 38” (2 passes)
Minimum Length 2-1/4”
Maximum Thickness 4”
Minimum Thickness 1/32”
Dimensions 36” x 42” x 24” (without stand)
Drum diameter 5” diameter - 1740 rpm.
Dust port diameter 4”
Height Adjustment 1/16” per revolution (depth scale included)
Conveyor Motor
Drive Motor (TEFC)
Power Requirements 110 V, 1 Ph, 20 A
Shipping Weight (3 boxes) 286 lbs (weight varies on how equipped)
2 YEAR WARRANTY
Limited warranty. We will provide all replacement parts which are found to be defective in materials or work-
and mailing in the warranty registration card supplied in the package with each new machine.
NOTE: You can also register online using our fast and easy warranty form by visiting our website at
www.SuperMaxTools.com
comply with all local codes and ordinances.
Fig. 1: Grounding Methods
