2-2
Super AOC-MGP-i2/i4 Add-on Card User's Guide
The AOC-MGP-i4 Layout
The AOC-MGP-i4 Image
MAC CODE
JPL1
BAR CODE
AOC-MGP-i4
REV: 1.00
DESIGNED IN USA
LAN1
LAN2
Intel
i350-AM4
LAN3
LAN4
Components
1. Intel i350-AM4 4. RJ45 LAN Port 3
2. RJ45 LAN Port 1 5. RJ45 LAN Port 4
3. RJ45 LAN Port 2 6. JPL1
1
5
1
4
1
3
1
2
1
1
1
6
