Chapter 2: Hardware Components

2-1

MAC CODE

JPL1

BAR CODE

AOC-MGP-i2

REV: 1.00

DESIGNED IN USA

LAN1

LAN2

Intel

i350-AM2

Chapter 2

Hardware Components

2-1 Add-On Card Image and Layout

The AOC-MGP-i2 Image

The AOC-MGP-i2 Layout

Components

1. Intel i350-AM2 3. RJ45 LAN Port 2

2. RJ45 LAN Port 1 4. JPL1
