H11DSi / H11DSi-NT User's Manual
Note: The table above is continued on the next page.
Motherboard Features
CPU
•
Dual EPYC 7001/7002* Series Processors, in Socket SP3. (*AMD EPYC 7002 series drop-in support requires board
revision 2.x)
Memory
•
2 TB of ECC DDR4 2666 MHz speed/ 4TB of ECC DDR4 3200 MHz* speed, RDIMM/LRDIMM/3DS/NVDIMM memory in
Sixteen (16) slots (*Board reversion 2.x required)
DIMM Size
• Up to 128GB size at 1.2V
Chipset
•
System on Chip
Expansion Slots
•
2 x PCI-E 3.0 x16
• 3 x PCI-E 3.0 x8
• 2 x Internal NVMe Ports (PCI-E 3.0 x4)
• M.2 Interface: 1 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
Network
•
Dual RJ45 LAN Ports (H11DSi-NT: Intel X550-BT2 / (H11DSi: I350-BT2)
• ATEN IPMI from ASPEED AST 2500 BMC for gigabit RJ45 port
Graphics
•
ASPEED AST2500 BMC chip with one (1) VGA port
I/O Devices
•
COM Port • One (1) COM connector on rear I/O panel
• SATA/NVMe Ports
• Eight (8) SATA 3.0 ports (iPASS)
• Two (2) SATA-DOM ports
• Two (2) internal NVMe ports (H11DSi-NT only)
Peripheral Devices
•
Two (2) USB 3.0 “Type A” ports on the rear I/O panel (USB 4/5)
• Two (2) USB 2.0 “Type A” ports on the rear I/O panel (USB 0/1)
• One (1) USB 2.0 header for front control panel (USB 2/3)
Motherboard Features

Supermicro H11DSi-NT Specifications

General

USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	16
Supported DIMM module capacities	8GB, 16GB, 32GB, 64GB, 128MB
ECC	Yes
Memory voltage	1.2 V
Memory channels	Octa-channel
Supported memory types	DDR4-SDRAM
Maximum internal memory	2048 GB
Supported memory clock speeds	2666 MHz
BIOS type	EEPROM
ACPI version	5.1
System Management BIOS (SMBIOS) version	3.1.1
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
AMD Opteron series	7000
Processor manufacturer	AMD
Processor number of cores supported	32, 28
Wi-Fi	No
Ethernet interface type	10 Gigabit Ethernet
Number of SATA III connectors	10
Trusted Platform Module (TPM) version	2.0
Sustainability certificates	RoHS
Motherboard form factor	Extended ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	331 mm
Width	305 mm
