Chapter 2: Installation
Watch Dog
JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system
when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the
system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt
signal for the application that hangs. Watch Dog must also be enabled in BIOS. The default
setting is Reset.
Note: When Watch Dog is enabled, the user needs to write their own application software
to disable it.
Watch Dog
Jumper Settings
Jumper Setting Denition
Pins 1-2 Reset (Default)
Pins 2-3 NMI
Open Disabled
VGA Enable/Disable
JPG1 allows you to enable or disable the VGA port. The default position is on pins 1 and 2
to enable VGA. See the table below for jumper settings.
VGA Enable/Disable
Jumper Settings (JPG1)
Jumper Setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled
PCI Slot SMB Enable (JI2C1/JI2C2)
Use Jumpers JI2C1/JI2C2 to enable PCI SMB (System Management Bus) support to improve
system management for the PCI slots. See the table on the right for jumper settings.
PCI Slot_SMB Enable
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled (Default)

Supermicro H11DSi-NT Specifications

General

USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	16
Supported DIMM module capacities	8GB, 16GB, 32GB, 64GB, 128MB
ECC	Yes
Memory voltage	1.2 V
Memory channels	Octa-channel
Supported memory types	DDR4-SDRAM
Maximum internal memory	2048 GB
Supported memory clock speeds	2666 MHz
BIOS type	EEPROM
ACPI version	5.1
System Management BIOS (SMBIOS) version	3.1.1
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
AMD Opteron series	7000
Processor manufacturer	AMD
Processor number of cores supported	32, 28
Wi-Fi	No
Ethernet interface type	10 Gigabit Ethernet
Number of SATA III connectors	10
Trusted Platform Module (TPM) version	2.0
Sustainability certificates	RoHS
Motherboard form factor	Extended ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	331 mm
Width	305 mm
