SuperServer E300-9A User's Manual
Jumper Description Default Setting
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 CMOS Clear Open (Normal)
JI
2
C1, JI
2
C2 SMB to PCI-E Slots Enable/Disable Both Pins 2-3 (Disabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN1/2/3/4 Enable/Disable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPTG1 10Gb LAN Enable/Disable Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
LED Description Color/State
LED1 Onboard Power LED Solid Green: Power On
LED2 UID LED
LEDM1 BMC Heartbeat LED
Blinking Green: BMC
Normal
LEDT1 LAN8 Activity Blinking Green: LAN8 Active
LEDT2 LAN7 Link Status Solid Green: LAN7 Normal
LEDT3 LAN7 Activity Blinking Green: LAN7 Active
LEDT4 LAN8 Link Status Solid Green: LAN8 Normal
Connector Description
BT1 Onboard Battery
COM1 COM Header
FAN1, FAN2, FAN3,
FANA
System/CPU Fan Headers (FAN1: CPU Fan)
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA3 Intel® PCH SATA 3.0 Ports (I-SATA0 is SuperDOM)
JD1 Speaker Header
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JL1 Chassis Intrusion Header
JLANLED1 LAN3/LAN4 Activity LED Header
JMD1 M.2 PCI-E 3.0 x4 / I-SATA4
JMP1 Mini PCI-E 2.0 x1 / I-SATA5 Slot
JPH1
4-pin Power Connector for HDD use (To provide power from the motherboard to onboard HDD
devices)
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPV1 12V DC Power Connector
JPW1 24-pin ATX Power Connector
JRT3 Thermal Diode 1 Header
JRT4 Thermal Diode 2 Header
JSD1 SATA DOM Power Connector
JSMB1 PCH SMBus Header
