Chapter 2 Maintenance and Component Installation
Installing the Hard Drive
The motherboard should be installed before installing the drive.
1. Make sure there is no power to the system as described in section 2.1 and remove the
chassis cover.
2. Remove the screws securing the hard drive tray to the support bracket and set them
aside for later use. Lift the tray out.
3. Place the drive into the tray and secure it to the tray with the screws provided with drive.
2.4 Chassis Components
Installing the Storage Drive
installed to a mounting tray inside the chassis. Use an enterprise quality drive.
Figure 2-4. Installing the Hard Drive
