SuperServer E300-9A User's Manual
System Features
Motherboard
A2SDi-TP8F
Chassis
Compact Embedded Mini ITX Box, SCE300
CPU
Intel® Atom® C3858 (System on a Chip) in FCBGA1310 format; CPU TDP support 25W
Memory
Memory types 2400/2133/1866/1600MHz; DIMM sizes 16GB, 8GB ,and 4GB
Expansion Slots
M2 Interface: PCI-E 3.0x2 or SATA3
Form Factor: M Key 2242/2280
Storage Drives
Mini PCI-E mSATA
M.2 PCI-E 3.0 x4 (SATA support)
Power
84W DC power adapter
Input/Output Ports
SATA: Two SATA3 (6Gbps) ports
LAN: Four RJ45 Gigabit Ethernet LAN ports, Two 10G SFP+ LAN ports, Two RJ45 10GBase-T ports and One
RJ45 Dedicated IPMI LAN port
USB: Two USB 3.0 ports (rear)
Display: One VGA port
DOM: One SuperDOM (Disk on Module) power connector
TPM: One TPM 2.0 header
Cooling
Two 40mm chassis fans, passive CPU heat sink
Front Panel
Dimensions
10 x 1.7 x 8.9 in. / 254 x 43 x 226 mm. (W x H x D)
1.2 System Features
The following table provides an overview of the main features of the E300-9A. Please refer
