Chapter 3 Motherboard Connections
Watch Dog
JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system
when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system
if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for
the application that hangs. Watch Dog must also be enabled in BIOS.
Note: When Watch Dog is enabled, users need to write their own application software to
disable it.
Watch Dog
Jumper Settings
Jumper Setting Denition
Pins 1-2 Reset (Default)
Pins 2-3 NMI
Open Disabled
SMBus to PCI-E Slots

improve system management for the onboard PCI-E slot.
SMBus to PCI-E Slots
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled (Default)
Mini-SAS HDD NVMe/SATA Mode Select

SMBus to PCI-E Slots
Jumper Settings
Jumper Setting Denition
Pins 1-2 SATA (Default)
Pins 2-3 NVMe
USB Wake Up

to wake up the system by pressing a key on the USB keyboard or by clicking the USB mouse.

will be active on all USB ports.
USB Wake Up
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
