2-12
X10DRL-i Motherboard User’s Manual
Memory Support for the X10DRL-i Motherboard
The X10DRL-i Motherboard supports up to 512 GB of DDR4 Registered (RDIMM)/
Load Reduced (LRDIMM) ECC 2133/1866/1600 MHz memory modules in eight
DIMM slots. Memory speed support is pending on the processors used in the sys-
tem. For the latest memory updates, please refer to our website a at http://www.
supermicro.com/products/motherboard.
Processor & Memory Module Population Conguration
For memory to work properly, follow the tables below for memory installation.
Processors and their Corresponding Memory Modules
CPU# Corresponding DIMM Modules
CPU 1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 P1-DIMMD1
CPU 2 P2-DIMME1 P2-DIMMF1 P2-DIMMG1 P2-DIMMH1
Processor and Memory Module Population for Optimal Performance
Number of
CPUs+DIMMs
CPU and Memory Population Conguration Table
(For memory to work properly, please follow the instructions below.)
1 CPU &
2 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1
1 CPU &
4 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1
2 CPUs &
4 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1
2 CPUs &
6 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1
2 CPUs &
8 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1
Populating RDIMM/LRDIMM ECC Memory Modules












   
 


     











 
 









   
     
   
     
   
  

 
   
     
DIMM
Capacity (GB)
Speed (MT/s)
Voltage (V)
Ranks
Per DIMM
and
Data Width
Type
