4-10
X10DRL-i Motherboard User’s Manual
CPU T State Control (Available when Power Technology
is set to Custom)
ACPI (Advanced Conguration Power Interface) T-States
Select Enable to support CPU throttling by the operating system to reduce power
consumption. The options are Enable and Disable.
FAST_RAPL_NSTRIKE_PL2_DUTY_CYCLE
This feature displays the value of the item above within the range between 25
(10%) and 64 (25%). The default setting is 64.
Turbo Power Limit Lock
Select Enable to set the power use limit for the machine when it is running in
the turbo mode. The options are Enable and Disable.
Long Power Limit Override
Select Enable to support long-term power limit override. If this feature is disabled,
BIOS will set the default value. The options are Enable and Disable.
Long Duration Power Limit
This item displays the power limit set by the user during which long duration
power is maintained. The default setting is 0.
Package Clamping Limit1
Use this item to set the limit on power performance states for the runtime proces-
sor, with P0 being the state with the highest frequency (clock speed) and power
(consumption), and P1, a step lower in performance than P0, with its frequency
and voltage scaled back a notch. The options are Between P1/P0 and Below P1.
Short Duration Power Limit Enable
Select Enable to support Short Duration Power Limit (Power Limit 2). The options
are Enable and Disable.
Short Duration Power Limit
This item displays the time period during which short duration power is main-
tained. The default setting is 0.
Package Clamping Limit2
Use this item to set the limit on power performance states for the processor
operating in turbo mode, with P0 being the state with the highest frequency
(clock speed) and power (consumption), and P1, a step lower in performance
