Fan Headers
The X11SSH-F/-LN4F has ve fan headers (Fan1-Fan4, FanA). All these 4-pin fans headers
are backward-compatible with the traditional 3-pin fans. However, fan speed control is
available for 4-pin fans only by Thermal Management via the IPMI 2.0 interface. Refer to the
table below for pin denitions.
Headers
Fan Header
Pin Denitions
Pin# Denition
1 Ground (Black)
2 2.5A/+12V (Red)
3 Tachometer
4 PWM_Control
1. FANA
2. FAN1
3. FAN2
4. FAN3
5. FAN4
1
23
5
4
