Supermicro X13DAI-T User Manual

28
Super X13DAI-T User's Manual
1. The 5th/4th Gen. Intel Xeon Scalable Processors (Component Side)
2. Processor Carrier (Top View)
The processor carrier assembly includes a processor and a processor carrier as shown
below.
SP XCC
SP XCC
Carrier E1A
Carrier E1A
3. Processor Carrier Assembly (with processor seated inside the carrier)
Overview of the Processor Carrier Assembly
The processor carrier assembly contains a 5th/4th Gen. Intel Xeon Scalable processor and
a processor carrier. Carefully follow the instructions given in the installation section to place
a processor into the carrier to create a processor carrier assembly.
Carrier E1A with
SP XCC Installed
SP MCC
SP MCC
Processor (2D)
Processor (3D)
Processor Carrier (3D)Processor Carrier (2D)
Carrier E1B
Carrier E1B
Carrier E1B with
SP MCC Installed
