Super X13DAI-T User's Manual
6. After the processor is placed inside the carrier, examine the four sides of the processor,
making sure that the processor is properly seated on the carrier.
SP XCC
Processor Carrier Assembly
(Component Side)
Processor Carrier Assembly
(Top View)
SP MCC
