Super X13DAI-T User's Manual
Front Control Panel (JF1) LEDs
Front Control Panel (JF1)
LED Indicators
Event
Power
(LED1)
HDD
(LED2)
LAN
(LED3/4)
Information
(LED5)
Power Fail
(LEDPWR)
Power On Solid On
HDD Activity
Blinking
NIC Activity
Blinking
Overheat
Solid On
Fan Fail
Blinking at 1Hz
Power Fail
Blinking at 1/4Hz Solid On
Checking
BMC/BIOS
Blinking at 4HZ
Recovering/Updating
BMC Blinking
at 4HZ
BMC 2 Blinks
at 4Hz,
1 Pause at 2Hz
(on-on-o󰀨-o󰀨)
Flash Not Detected or
Golden Image Check
Failed
BMC/BIOS
Blinking at 1HZ
CPLD Recovery Mode
Blinking at 10Hz
(FP Red LED)
