SUPER 370SBA/370SBM/370SLA/370SLM User’s Manual
viii
Jumpers Quick Reference
370SBA/
370SLA/
370SBM 370SLM
Jumpers Jumpers Function Page
JBT1 JBT1 CMOS Clear 2-6
JPWAKE JPWAKE Keyboard Wake-Up 2-7
JP11 JP11 Bus Speed 2-7
Connectors Connectors Function Page
J8 J8 AGP Port 2-11
J15, J16 J15, J16 IDE Connectors 2-10
J17, J18 J17, J18 USB Ports 2-5
J19 J19 Parallel Port 2-10
J20 J20 COM1 2-6
J21 J21 COM2 2-6
J22 J22 Floppy Connector 2-10
J32 J32 ATX Power Connector 2-3
J34 J34 PS/2 Keyboard and Mouse 2-5
JF1: 1-4 JF1: 1-4 IDE LED 2-4
JF1: 5-7 JF1: 5-7 Power ON LED 2-5
JF1: 8-9 JF1: 8-9 Keylock 2-5
JF1: 10-13 JF1: 10-13 Speaker 2-5
JF2: 1-5 JF2: 1-5 IR (Infrared) Connector 2-4
JF2: 9-10 JF2: 7-8 Power ON Switch 2-4
JF2: 12-13 JF2: 10-11 Reset Switch 2-4
JOH: 1-2 JOH: 1-2 Overheat LED 2-7
JL1 JL1 Chassis Intrusion Switch 2-7
JT1 JT1 CPU Fan 2-6
JT2 JT2 Chassis Fan 2-6
JT3 JT3 Thermal Control Fan 2-6
WOL WOL Wake-on-LAN 2-6
