Chapter 1: Introduction
1-5
X8DTL-3/X8DTL-3F/ X8DTL-i/ X8DTL-iF Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JI
2
C1/JI
2
C2 SMB to PCI/PCI-E Slots Open/Open (Disabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/2 Enable Pins 1-2 (Enabled)
JPS1 SAS Enable Pins 1-2 (Enabled) (X8DTL-3/3F)
JPS2 SAS RAID Select Closed (SR RAID Enabled) (X8DTL-3/3F)
JWD Watch Dog Pins 1-2 (Reset)
Connector Description
COM1/COM2 COM1/COM2 Serial Port/Header
FAN 1-6 System/CPU Fan Headers (Fans 1~2: CPU Fans)
I-Button I-Button for RAID data storage (for X8DTL-3/3F only)
IPMB IPMB I
2
C Header (for an IPMI card) (for X8DTL-iF/3F only)
JPI
2
C Power Supply SMBbus I
2
C Header
JD1 PWR LED/Speaker Header (Pins 4~7: Speaker)
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPW1, JPW2/JPW3 24-pin ATX PWR, 8-pin Secondary PWR (*Warning P. 1-4)
JWF1 DOM (Disk-On-Module) Power Connector (Note 1 on P.1-3.)
JWOL Wake-On-LAN Header
JWOR Wake-On-Ring Header (See Note 1 on P. 1-3.)
LAN1/2, Dedicated LAN G-LAN (RJ45) Ports (Dedicated LAN: X8DTL-iF/3F)
I-SATA0 ~ I-SATA5 (Intel South Bridge) SATA Ports
SAS 0~7 SAS Ports 0~7 (for X8DTL-3/-3F only)
SP1 Internal Buzzer
3-SGPIO-1/3-SGPIO-2 Serial General Purpose I/O Headers for SAS (X8DTL-3/3F)
T-SGPIO-1/T-SGPIO-2 Serial General Purpose I/O Headers for SATA
USB 0/1, 2/3, 4/5, 6 Universal Serial Bus (USB) Ports
UID Rear Unit Identify Switch
VGA VGA Connector
LED Description
D20 BMC Heartbeat LED Indicator
LE1 Onboard Standby LED Indicator
LE2 Rear UID LED
LES2 SAS Heartbeat LED
