Supero X10SRi-F User Manual

Chapter 1: Introduction
1-5
X10SRi-F Headers/Connectors
Connector Description
Battery (BT1) Onboard Battery
COM1/COM2 COM1 (Port)/COM2 (Header)
Fan1 - Fan5, FanA System/CPU Fan Headers
JD1 Speaker/Buzzer (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JPI
2
C1 Power SMB (System Management Bus)
J24 24-pin ATX Main Power Connector (Required)
JOH1 Overheat/Fan Fail LED Indicator
JPWR1 +12V 8-pin CPU power Connector (Required)
JSD1/JSD2 SATA DOM (Device_On_Module) Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID (Unit Identier) Switch
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
IPMI_LAN IPMI_Dedicated LAN
I-SATA0~5, S-SATA0~3 (Intel PCH) Serial ATA (SATA 3.0) Ports 0/1 (6Gb/sec)
(PCH) Slots 1/2 PCI-Express 2.0 Slots: Slot1 x2 (in x8), Slot2 x4 (in x8)
(CPU) Slots 3/4/5/6 PCI-Express 3.0 Slots: Slot3 x8, Slot4 x8, Slot5 x4 (in x8), Slot6 x16
SP1 Internal Speaker/Buzzer
T-SGPIO 1/2/3 Serial_Link General Purpose I/O Headers 1/2/3 for SATA Connections
USB 0/1 Backpanel USB 2.0 Ports 0, 1
USB 2/3 (3.0) Backpanel USB 3.0 Ports 2, 3
USB 4/5, 6/7, 8/9 Front Panel Accessible USB 2.0 Headers 4/5, 6/7, 8/9
USB 10, USB 11 Front Panel Accessible USB 3.0 Header 10, Type A Header 11
VGA Backpanel VGA Port
X10SRi-F LED Indicators
LED Description State/Color Status
LE1 UID LED Blue: On Unit Identied
LE2 Onbaord Power LED Green: On System Power On
LEDM1 BMC Heartbeat LED Green: Blinking BMC Normal
