2023-11-30 38 2301122
Speed must be greater than 85% of the Setspeed.
Setspeed must be greater than 7 mph and less than 30 mph.
The Inclinometer must be Active.
Roll is either above 1.5° or below -1.5°
Once the above parameters have been met, Autoleveling will retract the plate on the side of the
roll fully to 0% and launch the plate opposite of the roll immediately to 40% and begin
incrementing in steps of 5% until either the roll has been leveled or the plate has extended to
the maximum setpoint of 65%.
Example: If the boat is leaning to the port side the port plate will retract to 0% and the starboard
plate will extend to 40%. If the boat is still not level after the initial extension the boat will then
increment by 5% until roll has reached level or 65%, whichever comes first. If the boat
overcorrects the roll, the plate that extended will begin to retract in 5% increments until roll is
corrected or until the plate is back at 0%. If the plate retracts back to 0%, the plate opposite to
the one previously retracted will then begin to extend like it would in normal operating
conditions.
NOTE: Autoleveling is disabled when turning.
