Introduction
CS-40 status LED
The status of CS-40 can be confirmed through STATUS LED 1 / 2 located on the left side from the front unit of the
product. These status LEDs show the status of Ethernet, RS-485 0, RS-485 1, RS-485 2, RS-485 3, RS-485 HOST, and system
in order for 1 second each.
Feature LED 1 LED 2 Status
Ethernet
Red Red Connection to a dynamic IP failed.
Red Yellow Connection to a dynamic IP is on standby.
Red
Sky blue
Connection to a static IP succeeded.
Red Blue Connection to a dynamic IP succeeded
Red Magenta Connection to a static IP failed.
Red
Off
HW error
RS-485 0
Yellow
Red
No slave device
Yellow Yellow The slave device is disconnected.
Yellow Blue The slave device is normal.
Yellow
Off
HW error
RS-485 1
Green
Red
No slave device
Green Yellow The slave device is disconnected.
Green Blue The slave device is normal.
Green
Off
HW error
RS-485 2
Sky blue
Red
No slave device
Sky blue Yellow The slave device is disconnected.
Sky blue Blue The slave device is normal.
Sky blue
Off
HW error
RS-485 3
Blue
Red
No slave device
Blue Yellow The slave device is disconnected.
Blue Blue The slave device is normal.
Blue
Off
HW error
RS-485 HOST
Magenta
Red
No slave device
Magenta Yellow The slave device is disconnected.
Magenta Blue The slave device is normal.
Magenta
Off
HW error
System
White
Red
System locked (by trigger & action of device)
White Yellow System locked (by trigger & action of BioStar 2)
White
Green
Connection to BioStar 2 succeeded
White
Sky blue
Connection to BioStar 2 succeeded + Tamper ON
White Blue Tamper ON
White Magenta System locked (by trigger & action of device) + Tamper ON
White
White
System locked (by trigger & action of BioStar 2) + Tamper ON
Magenta Magenta Migrating the database
