suprema CST-4DR-D2G User Manual

10
Introduction
Installation example
CS-40 is a centralized access control system that can perform biometric authentication. CS-40, designed as an enterprise
system, can save the information of up to 500,000 users and execute matching of 400,000 fingerprints per second.
Both access control and attendance management can be used through the linkage with BioStar 2, and various interfaces
are provided, including RS-485 (OSDP), Wiegand, Supervised input, and AUX.
5
System diagram
Up to 64 RS-485 devices can be connected to CS-40, and when DM-20 is connected using a daisy chain, Wiegand devices
can be expanded up to 132.
5
Sensor
Wiegand
Reader
Door
Outside
Door
Inside
Door
Lock
Door
Sensor
Alarm
RS-485
Slave
Device
Relay
Input / output
Wiegand
RS-485
DM-20
Card
Reader
Card / Fingerprint
Reader
OM-120
Elevator Panel
Card
Reader
DM-20
Card
Reader
Card
Reader
DM-20
Card
Reader
Fingerprint
Reader
Card
Reader
Card
Reader
Fingerprint
Reader
CoreStation
Alarm Sensor (8ch TTL / Supervised input)
Elevator Control
USB
TCP/IP TCP/IP
WAN
WAN
BioStar 2 Server
Web Browser
(BioStar 2 Client)
Remote Access
Internet
Web Browser
(BioStar 2 Client)
BioStar 2 Mobile
BioMini
(Fingerprint Enrollment Device)
DE-620
(Smartcard Reader/Writer)

suprema CST-4DR-D2G Specifications

General

Brand	suprema
Model	CST-4DR-D2G
Category	Controller
Language	English
