External LED Indicator
11, External Bluetooth LED indicator – J7
When Bluetooth is paired, the LED will be ON;
When Bluetooth is searching, the LED will BLINK.
11
12
12, External Power LED indicator – J6
Pin 3,4 of J6 is used as power LED indicator.
When powered on, the LED will be ON;
When powered off, the LED will be OFF.
J7
J6
