01.
Connection
02.
Input
03.
Output
Connecting Audio Cables
Use the 10 pin to 10 pin cornoid
to connect APM2 with interface
extension kit (APM3) for playing
music.
This interface extension kit
(APM3) provides three methods
of audio input:
✓ RCA
✓ 3.5mm Aux
✓ PH-4PIN-2MM
This interface extension kit
(APM3) provides three channels
of audio output:
✓ RCA
✓ 3.5mm Headphone
✓ PH-4PIN-2MM
RCA 3.5mm Aux PH-4PIN-
2MM
RCA 3.5mm
Headphone
PH-4PIN-
2MM
