B
B-1
B. Cable Requirements
The following diagram and table show the standard RJ-45 receptacle/connector and
their pin assignments for the switch-to-network interface card connection, and the
straight/crossover cable for the Switch-to-switch/hub/bridge connection.
The standard RJ-45 receptacle/connector
Contact Media Direct Interface Signal
1 Tx + (transmit)
2 Tx - (transmit)
3 Rx + (receive)
4 Not used
5 Not used
6 Rx - (receive)
7 Not used
8 Not used
The standard Category 3 , 4 or 5 cable, RJ-45 pin assignment
RJ-45 Connector pin assignment
2-Year Warranty
The manufacturer warrants to the original consumer /purchaser free from defects
in materials or workmanship for limited time from the original factory shipment
date.
KEEP THIS STUB FOR YOUR RECORDS
Date Purchased:
Where Purchased:
From Whom:
Model: Serial:
MANUFACTURER DISTRIBUTOR
Name/Title:
Company:
Address:
Tel. No.: Signature:
Purchase Model: Serial No.:
Purchase from:
Address:
Date of Purchase:
WARRANTY REGISTRATION CARD
Please complete this form and return it within 10
days of purchase to validate the warranty
Place
Stamp
Here
