6-36
LIGHT BULB REPLACEMENT
The wattage rating of each bulb is
shown on the chart below. When
replacing a burned out bulb, always
use the exact same wattage rating.
Using other than the specified rating
can result in overloading the electrical
system or premature failure of a bulb.
HEADLIGHT BULB REPLACEMENT
To replace the headlight bulb, follow
the procedure below:
1. Remove the right and left fasten-
ers.
2. Unhook the hooks and remove the
rear handle cover 1.
3. Remove the front handle cover 2.
NOTICE
Failure to use a light bulb with the
correct wattage rating can over-
load the electrical system of your
motorcycle or cause the bulb to
burn out sooner.
Use only the light bulbs shown in
the chart as replacement bulbs.
Headlight 12V 60/55W (H4) × 2
Front turn signal light 12V 21W × 2
Rear turn signal light 12V 21W × 2
Brake light/Taillight 12V 21/5W × 2
License plate light 12V 5W
