AY50K1 K2/WRK1 K2 (’01 ’02-MODEL) 11-15
INSPECTION
Check the operating temperature of the engine coolant temp.
switch.
• Place the engine coolant temp. switch into a container of oil.
• Heat the oil and check the temperature on the thermometer
when the engine coolant temp. switch is operated.
# 09900-25008: Multi circuit tester set
" Engine coolant temp. switch specification:
OFF
→→
→→
→ON: Approx. 125 °C
ON
→→
→→
→OFF: Approx. 118 °C
INSTALLATION
Install the engine coolant temp. switch in the reverse order of
removal. Pay attention to the following points:
• Apply SUZUKI BOND No. 1215 to the thread portion of the
engine coolant temp. switch.
$ 99000-31110: SUZUKI BOND No.1215
• Tighten the engine coolant temp. switch 1 securely and con-
nect the lead wire.
