Suzuki AY50 - Headlight; High Beam Indicator Light; Oil Level Indicator Light; Speedometer Light

12-8 AY50K3/SK3/WK3/WSK3 (’03-MODEL)
WATTAGE
Unit: W
BRAKE + WHEEL
Unit: mm
SUSPENSION
Unit: mm
ITEM SPECIFICATION
Headlight HI 35
LO 35
Brake light/Taillight 21/5
Turn signal light 10
Speedometer light 1.2 × 2
Fuel meter light 1.2
Turn signal indicator light 2
Oil level indicator light 2
High beam indicator light 1.7
Trunk light 2
ITEM STANDARD LIMIT
Brake lever play Rear 15 – 20 —
Brake drum I.D. Rear — 120.7
Brake disc thickness Front 4.0 ± 0.2 3.5
Brake disc runout Front — 0.30
Master cylinder bore Front 11.000 – 11.043 —
Master cylinder piston diam. Front 10.957 – 10.984 —
Brake caliper cylinder bore Front 30.230 – 30.306 —
Brake caliper piston diam. Front 30.150 – 30.200 —
Brake fluid type DOT 4 —
Wheel rim runout Axial — 2.0
Radial — 2.0
Wheel axle runout Front — 0.25
Wheel rim size Front J12 × MT3.50 —
Rear J12 × MT3.50 —
Tire size Front 120/70-12 51L —
Rear 130/70-12 56L —
Tire type Front MICHELIN: DEXTER —
Rear MICHELIN: DEXTER —
Tire tread depth Front — 1.6
Rear — 1.6
ITEM STANDARD LIMIT
Front fork stroke 77 —
Front fork spring free length 124.7 122
Rear wheel travel 60 —
