Suzuki DF200AP User Manual

84
BREATHER AND FUEL LINE
Inspect the breather and fuel line for leaks,
cracks, swelling, or other damage. If the
breather and fuel line are damaged in any way,
they must be replaced. Consult your authorized
Suzuki Marine dealer if it is necessary to
replace them.
Breather line
Fuel line
Fuel line
 WARNING
Fuel leakage can contribute to an explo-
sion or fire, resulting in serious personal
injury.
Have your authorized Suzuki marine
dealer replace the fuel line if there is any
evidence of leaking, cracking or swelling.

Suzuki DF200AP Specifications

General

Displacement	2, 867 cc
Bore x Stroke	97 mm x 97 mm
Starting System	Electric
Steering	Remote
Trim Method	Power Trim and Tilt
Number of Cylinders	4
Maximum Output (kW)	147 kW
Exhaust	Through Prop Hub Exhaust
Engine Type	DOHC 16-Valve
Maximum Output	200 PS
Fuel Delivery System	Sequential Multi Point Fuel Injection
Full Throttle Operating Range	5500 - 6100 rpm
Alternator Output	44 A
Shaft Length	L: 508 mm
