80
NOTE:
Before applying grease through the steering
bracket grease nipple, lock the motor in the fully
tilted up position.
Marine-grade
water resistant
grease
(Grease Gun)
Swivel bracket
Steering bracket
Clutch lever
Engine holder
Use a hand operated grease gun and follow the
steps below when servicing the grease nipple
A on the engine holder.
1. Turn the engine off and allow it to cool.
2. Inject approximately 10 grams of grease at
initial 20 hours.
Inject approximately 5 grams of grease at
every 100 hours (12 months).
NOTE:
If it is difficult to inject the grease in correct vol-
ume, consult your Authorized Suzuki Marine
Dealer.
ANODES AND BONDING WIRES
Anodes
The motor is protected from exterior corrosion
by anodes. These pieces of anodes control
electrolysis and prevent corrosion. The anodes
will corrode in place of the parts they are pro-
tecting. You should periodically inspect each of
the anodes and replace them when 2/3 of the
metal has corroded away.
NOTICE
Using a hydraulic or air powered grease gun
to service the grease nipple
A
on the engine
holder may cause damage to the oil seal.
Do not use powered grease guns when servic-
ing grease nipple
A
on the engine holder.
