56
4. Inspect the fuse and replace with the new
fuse if needed.
NOTE:
If a fuse is blown, try to determine the root
cause and correct it.
If the cause is not corrected, the fuse may be
blown again.
Normal fuse
Blown fuse
WARNING
If you replace a blown fuse with a fuse having
a different amperage rating or with a substi-
tute such as aluminum foil or a wire, extensive
electrical system damage and a fire may
result.
Always replace a blown fuse with a fuse of the
same type and rating.
NOTICE
If a new fuse blows in a short time after instal-
lation, you may have a major electrical system
problem.
Consult your SUZUKI marine dealer.
SPECIFICATIONS
Item DF8A DF9.9A
Engine Type 4 Stroke
Number of Cylinders 2
Bore and Stroke 51.0 × 51.0 mm (2.00 × 2.00 in.)
Piston Displacement 208 cm
3
(12.7 cu. in.)
Maximum output 5.9 kW (8PS) 7.3 kW (9.9PS)
Full Throttle Operating Range 4700 – 5700
r/min. (min
–1
)
5200 – 6200
r/min. (min
–1
)
Ignition System Digital CDI
Engine Lubrication Trochoid pump pressure lubrication
Engine Oil Capacity 0.8 L (0.85/0.70 US/lmp. qt.)
Gear Oil Capacity 250 cm
3
(ml) (8.5/8.8 US/Imp. oz.)
Spark Plug NGK CR6E
Spark Plug Gap 0.7 – 0.8 mm (0.028 – 0.031 in.)
Valve Clearance (Lash) IN. : 0.16 – 0.20 mm (0.006 – 0.008 in.)
EX.: 0.16 – 0.20 mm (0.006 – 0.008 in.)
Fuel Type Alcohol-free unleaded gasoline
Minimum Fuel Octane Rating 91 (Research method)
