Suzuki DL650K6 - Throttle Body

THROTTLE BODY
CONSTRUCTION
Only for E-33
1 STP sensor 8 Secondary throttle link rod
2 TP sensor 9 Throttle link rod
3 O-ring 0 STVA &
4 Fuel delivery pipe/hose A STP sensor mounting screw ITEM N·m kgf-m lb-ft
5 Fuel injector B TP sensor mounting screw A 3.5 0.35 2.5
6 O-ring
C
Fuel delivery pipe mounting
screw
B 3.5 0.35 2.5
7 Cushion seal C 50.53.5
13-50 DL650K7/AK7 (’07-MODEL)
