Instrumentation / Driver Info. / Horn: 9C-10
Information Display Symptom Diagnosis (If Equipped)
S5JB0A9304015
NOTE
This thermometer indicates the ambient temperature in back of front bumper member. Under any one
of the following listed conditions, however, even when the ambient temperature goes up, the
thermometer display does not rise so as to correct the rise of the ambient temperature caused by the
radiant heat of the engine. When the ambient temperature drops, the thermometer reading follows the
change in the temperature.
Be sure to bear this in mind when diagnosing trouble.
• The vehicle speed is 30 km/h (18 mph) or lower.
• VSS signal is faulty.
• The ignition switch is turned on again within 2 hours.
Clock Symptom Diagnosis (If Equipped)
S5JB0A9304020
Condition Possible cause Correction / Reference Item
No displaying of
information display
Circuit fuse Blown Replace fuse and check for short circuit.
Wiring and/or grounding faulty Repair as necessary.
Information display unit faulty Replace unit.
Incorrect thermometer
display
Outside air temperature sensor faulty Check outside air temperature sensor referring
to “Outside Air Temperature Sensor Inspection
(If Equipped): ”.
Vehicle speed signal faulty Check ECM for DTC referring to “DTC Check:
in Section 1A”.
Wiring and/or grounding faulty Repair as necessary.
BCM faulty Replace after making sure that none of above
parts is faulty.
Display does not change
at –30
° C
Outside air temperature is –30 °C (–22
°F) or less
—
Outside air temperature sensor faulty Check outside air temperature sensor referring
to “Outside Air Temperature Sensor Inspection
(If Equipped): ”.
Outside air temperature sensor wiring
circuit open circuit and/or short to power
circuit
Repair as necessary.
BCM faulty Replace after making sure that none of above
parts is faulty.
Display does not change
at 50
° C
Outside air temperature is 50 °C (122
°F) or more
—
Outside air temperature sensor faulty Check outside air temperature sensor referring
to “Outside Air Temperature Sensor Inspection
(If Equipped): ”.
Outside air temperature sensor wiring
circuit short to ground circuit
Repair as necessary.
BCM faulty Replace after making sure that none of above
parts is faulty.
Condition Possible cause Correction / Reference Item
No displaying of clock Circuit fuse Blown Replace fuse and check for short circuit.
Wiring and/or grounding faulty Repair as necessary.
Clock unit faulty Replace unit.
