8-10 CHASSIS
REMOVAL AND DISASSEMBLY
• Remove the brake calipers.

• Loosen two axle pinch bolts 1 on the right front fork leg.
• Remove the front axle bolt 2.
• Remove the under cowling. (8-5)
• Raise the front wheel off the ground and support the motorcy-
cle with a jack or a wooden block.

• Loosen two axle pinch bolts 3 on the left front fork leg.
• Draw out the front axle and remove the front wheel.
NOTE:
After removing the front wheel, fit the calipers temporarily to the
original positions.
• Remove the collar 4.
Do not operate the brake lever while removing the cal-
ipers.
Do not carry out the work with the motorcycle resting
on the side-stand. Do not support the motorcycle with
the exhaust pipe. Make sure that the motorcycle is
supported securely.

Suzuki GSX-R600 2007 Specifications

General

Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Curb Weight	187 kg (412 lbs)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, liquid-cooled, DOHC
Rear Suspension	Link type, coil spring, oil damped
Overall Length	2040 mm
Overall Width	715 mm
Seat Height	810 mm
Ground Clearance	130 mm
Wheelbase	1400 mm
Fuel Tank Capacity	17.0 L (4.5 US gallons)
