8-84 CHASSIS
MASTER CYLINDER INSTALLATION
Install the master cylinder in the reverse order of removal. Pay
attention to the following points:
• Apply THREAD LOCK to the master cylinder mounting bolts.
 99000-32110: THREAD LOCK SUPER “1322”
(or equivalent thread lock)
• Tighten each bolt to the specified torque.
(Brake hose routing: 10-25)
 Brake hose union bolt 1: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
Master cylinder mounting bolt 2:
10 N·m (1.0 kgf-m, 7.0 lb-ft)
Master cylinder rod lock-nut 3:
18 N·m (1.8 kgf-m, 13.0 lb-ft)

• Adjust the brake pedal height. (2-25)
* The seal washers should be replaced with the new
ones to prevent fluid leakage.
* Bleed air from the system after reassembling the
master cylinder. (2-23)

Suzuki GSX-R600 2007 Specifications

General

Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Curb Weight	187 kg (412 lbs)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, liquid-cooled, DOHC
Rear Suspension	Link type, coil spring, oil damped
Overall Length	2040 mm
Overall Width	715 mm
Seat Height	810 mm
Ground Clearance	130 mm
Wheelbase	1400 mm
Fuel Tank Capacity	17.0 L (4.5 US gallons)
