8-44 CHASSIS
REASSEMBLY AND INSTALLATION
Reassemble and install the rear wheel in the reverse order of
removal and disassembly. Pay attention to the following points:
Left Right
100 N·m
(10.0 kgf-m, 72.5 lb-ft)
E-02, 19, 24
E-03, 28, 33
93 N·m
(9.3 kgf-m, 67.5 lb-ft)
35 N·m
(3.5 kgf-m, 25.5 lb-ft)
100 N·m
(10.0 kgf-m, 72.5 lb-ft)

Suzuki GSX-R600 2007 Specifications

General

Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Curb Weight	187 kg (412 lbs)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, liquid-cooled, DOHC
Rear Suspension	Link type, coil spring, oil damped
Overall Length	2040 mm
Overall Width	715 mm
Seat Height	810 mm
Ground Clearance	130 mm
Wheelbase	1400 mm
Fuel Tank Capacity	17.0 L (4.5 US gallons)
