CHASSIS 8-87
TIRE INSTALLATION
• Apply tire lubricant to the tire bead.
• When installing the tire onto the wheel, observe the following
points.

• When installing the tire, the arrow A on the side wall should
point to the direction of wheel rotation.
• Align the chalk mark put on the tire at the time of removal with
the valve position.
• For installation procedure of tire onto the wheel, follow the
instructions given by the tire changer manufacturer.
• Bounce the tire several times while rotating. This makes the
tire bead expand outward to contact the wheel, thereby facili-
tating air inflation.
• Inflate the tire.

* Do not reuse the valve which has been once
removed.
* Never use oil, grease or gasoline on the tire bead in
place of tire lubricant.
* Do not inflate the tire to more than 400 kPa (4.0
kgf/cm², 57 psi). If inflated beyond this limit, the tire
can burst and possibly cause injury. Do not stand
directly over the tire while inflating.
* In the case of preset pressure air inflator, pay special
care for the set pressure adjustment.

Suzuki GSX-R600 2007 Specifications

General

Bore x Stroke	67.0 mm x 42.5 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Curb Weight	187 kg (412 lbs)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, liquid-cooled, DOHC
Rear Suspension	Link type, coil spring, oil damped
Overall Length	2040 mm
Overall Width	715 mm
Seat Height	810 mm
Ground Clearance	130 mm
Wheelbase	1400 mm
Fuel Tank Capacity	17.0 L (4.5 US gallons)
