7-20 CHASSIS
BRAKE FLUID REPLACEMENT
• Place the vehicle on a level surface and keep the handlebar
straight.
• Remove the master cylinder reservoir cap and diaphragm.
• Suck up the old brake fluid as much as possible.
• Fill the reservoir with new brake fluid.
) Specification and classification: DOT 4
• Connect a clear hose to the air bleeder valve and insert the
other end of the hose into a receptacle.
• Loosen the air bleeder valve and pump the brake lever until
the old brake fluid is completely out of the brake system.
• Close the air bleeder valve and disconnect the clear hose. Fill
the reservoir with new brake fluid to the upper mark of the res-
ervoir.
" Brake air bleeder valve: 6 N·m (0.6 kgf-m, 4.5 lb-ft)
#
BRAKE CALIPER REMOVAL AND
DISASSEMBLY
• Remove the front wheel and front hub plate. (%7-10)
• Disconnect the brake hose from the brake caliper by remov-
ing the brake hose union bolt
1 and allow the brake fluid to
drain into a suitable receptacle.
• Remove the brake caliper by removing the brake caliper
mounting bolts
2.
• Remove the brake pads. (%7-19)
!
* Never reuse the brake fluid left over from previous
servicing and which has been stored for long peri-
ods of time.
* Bleed air from the brake system.
(%2-21)
Brake fluid, if it leaks, will interfere with safe running
and discolor painted surfaces. Check the brake hose,
brake pipe and hose joints for cracks and leakage of
brake fluid.
