3-22
BEFORE DRIVING
69TB-01E
ON: Lights ON
LIGHT: When it is light around the light sensor (5).
DARK: When it is dark around the light sensor (5).
Lighting
switch
position
Main lights to be
operated
Ignition mode
LOCK (OFF) or ACC
Ignition mode ON
LIGHT DARK LIGHT DARK
(1) OFF
Position lights,
Tail lights,
License plate light
––––
Headlights ––––
(2) AUTO
Position lights,
Tail lights,
License plate light
–––ON
Headlights – – – ON
(3)
Position lights,
Tail lights,
License plate light
ON ON ON ON
Headlights ––––
(4)
Position lights,
Tail lights,
License plate light
ON ON ON ON
Headlights ON ON ON ON
To turn the lights on or off, twist the knob
on the end of the lever. There are four
positions:
OFF (1)
All lights are off.
AUTO (2)
This function works when the engine
switch is pressed to change the ignition
mode to ON. The headlights, position
lights, tail lights and license plate light are
turned on and off automatically according
to the amount of outside light detected by a
sensor. They go out automatically when
you change the ignition mode to ACC or
LOCK (OFF) by pressing the engine
switch.
The light sensor (5) for sensing the amount
of outside light is installed on the passen-
ger’s seat side of instrument panel.
When the following conditions are met, you
can use the high beam assist.
• The engine switch is pressed to change
the ignition mode to ON
• The headlights are turned on when it
becomes dark outside the vehicle
• The lighting switch is in “AUTO” position
For details, refer to “High beam assist”
(P.5-92).
