4-12
INSTRUMENT CLUSTER
69TB-01E
• When you reconnect the negative (–)
terminal to the lead-acid battery, the
value of the total idling stop time and the
total idling fuel saved will be reset.
Clock and date
Date and time are shown. For the setting
procedure, refer to “Setting mode of infor-
mation display” (P.12-8).
Motion
69T040450
This indicates how the center of gravity is
moved while driving.
G (acceleration of gravity) position applied
to the vehicle body while driving is shown
by a globe (14).
When the vehicle is stopped, historical
data of G positions applied to the vehicle
body during the driving is shown as a
graph (15).
G position history graph at the vehicle
stopped can be changed to indicate or
hide. For details, refer to “Setting mode of
information display” (P.12-8).
NOTE:
• If G position history graph at the vehicle
stopped has been set in indication
mode, the graph (15) is shown for sev-
eral seconds when you change the igni-
tion mode to LOCK (OFF) after driving.
• The graph is shown approximately and
the actual movement may differ.
Torque and power
Present engine torque and power are
shown.
Accelerator and brake
Present accelerator pedal depressing
degree and brake line pressure are shown.
The display is selectable to indicate or not
to indicate. For details, refer to “Setting
mode of information display” (P.12-8).
Motion
Front
Rear
Motion
Front
Rear
R
L
R
L
(14) (15)
WARNING
Do not look in the display while driv-
ing. Doing so may result in an acci-
dent.
To Next Page
